Tunnel

// ═══ typeshade example — the classic tunnel (polar remap) ═══
//
// The demoscene / ShaderToy staple: remap the screen into polar coordinates
// (angle around the bore, 1/radius into the depth) so a flat checker pattern
// reads as an endless tunnel flying past. Showcases `atan2` (the divergent
// WGSL/GLSL spelling the intrinsic registry unifies), `length`, and
// screen-space fog. One DSL source → WGSL (WebGPU) + GLSL ES 3.00 (WebGL2).

import {
  fn,
  module,
  f32,
  vec3,
  vec4,
  sin,
  atan2,
  length,
  max,
  mix,
  clamp,
  smoothstep,
  Let,
  f32T,
} from '../src/index.js';
import { VsOut, vs, fullscreenUniforms, screenCoords } from './_fullscreen.js';
import type { ShaderExample } from './_shared.js';
const U = fullscreenUniforms({ twist: f32T });

const fs = fn(
  'fs',
  { vo: VsOut },
  ({ vo }) => {
    const t = U.field.time;
    const res = U.field.resolution;
    // centred, aspect-corrected plane
    const p = screenCoords(vo.uv, res);
    const r = Let(length(p));
    const a = atan2(p.y, p.x);
    // tunnel-surface coordinates: 1/r is the distance into the bore, the
    // angle wraps around it. Adding time to the depth flies the camera forward;
    // the twist uniform shears the angle by depth so the bore corkscrews.
    const depth = Let(f32(0.3).div(max(r, 0.001)).add(t.mul(1.4)));
    const ang = a.div(3.14159265).add(depth.mul(U.field.twist).mul(0.08));
    // checkerboard walls: two perpendicular square-ish waves
    const cw = sin(ang.mul(12.566)).mul(sin(depth.mul(9.4248)));
    const shade = smoothstep(-0.6, 0.6, cw).mul(0.55).add(0.35);
    // warm→cool tint cycling with depth, then fog toward the far centre
    const tint = mix(
      vec3(1.0, 0.62, 0.28),
      vec3(0.42, 0.3, 0.55),
      sin(depth.mul(0.9)).mul(0.5).add(0.5),
    );
    const fog = smoothstep(0.0, 0.55, r);
    const vig = clamp(f32(1.15).sub(r.mul(0.35)), 0, 1);
    return vec4(tint.mul(shade).mul(fog).mul(vig), 1);
  },
  { stage: 'fragment', retAttr: '@location(0)' },
);

const tunnelModule = module({
  structs: [U.struct, VsOut.decl],
  bindings: [U.binding],
  funcs: [vs, fs],
});

export const tunnel: ShaderExample = {
  id: 'tunnel',
  title: 'Tunnel',
  blurb:
    'The demoscene tunnel — the screen remapped to polar coordinates (angle around, 1/radius into the depth) so a checker pattern flies past forever. atan2 + length + fog, with a live twist control.',
  category: 'generic',
  file: 'tunnel.ts',
  module: tunnelModule,
  renderable: true,
  controls: {
    time: { kind: 'time' },
    resolution: { kind: 'resolution' },
    twist: { kind: 'slider', label: 'Twist', min: 0, max: 3, step: 0.1, value: 1 },
  },
};

struct Uniforms {
  time: f32,
  resolution: vec2<f32>,
  twist: f32,
}

struct VsOut {
  @builtin(position) pos: vec4<f32>,
  @location(0) uv: vec2<f32>,
}

@group(0) @binding(0) var<uniform> U: Uniforms;

@vertex
fn vs(@builtin(vertex_index) vi: u32) -> VsOut {
  let _cse0 = ((f32((vi & 1u)) * 4.0) - 1.0);
  let _cse1 = ((f32((vi >> 1u)) * 4.0) - 1.0);
  return VsOut(vec4<f32>(_cse0, _cse1, 0.0, 1.0), vec2<f32>(((_cse0 * 0.5) + 0.5), ((_cse1 * 0.5) + 0.5)));
}

@fragment
fn fs(vo: VsOut) -> @location(0) vec4<f32> {
  let _cse0 = vec2<f32>((((vo.uv.x * 2.0) - 1.0) * (U.resolution.x / U.resolution.y)), ((vo.uv.y * 2.0) - 1.0));
  let _v0 = length(_cse0);
  let _v1 = ((0.3 / max(_v0, 0.001)) + (U.time * 1.4));
  return vec4<f32>((((mix(vec3<f32>(1.0, 0.62, 0.28), vec3<f32>(0.42, 0.3, 0.55), ((sin((_v1 * 0.9)) * 0.5) + 0.5)) * ((smoothstep(-0.6, 0.6, (sin((((atan2(_cse0.y, _cse0.x) / 3.14159265) + ((_v1 * U.twist) * 0.08)) * 12.566)) * sin((_v1 * 9.4248)))) * 0.55) + 0.35)) * smoothstep(0.0, 0.55, _v0)) * clamp((1.15 - (_v0 * 0.35)), 0.0, 1.0)), 1.0);
}

#version 300 es
precision highp float;
precision highp int;

out vec2 uv;

void main() {
  uint vi = uint(gl_VertexID);
  float _cse0 = ((float((vi & 1u)) * 4.0) - 1.0);
  float _cse1 = ((float((vi >> 1u)) * 4.0) - 1.0);
  gl_Position = vec4(_cse0, _cse1, 0.0, 1.0);
  uv = vec2(((_cse0 * 0.5) + 0.5), ((_cse1 * 0.5) + 0.5));
}

#version 300 es
precision highp float;
precision highp int;

layout(std140) uniform Uniforms {
  float time;
  vec2 resolution;
  float twist;
} U;
in vec2 uv;
layout(location = 0) out vec4 _ret;

void main() {
  vec2 _cse0 = vec2((((uv.x * 2.0) - 1.0) * (U.resolution.x / U.resolution.y)), ((uv.y * 2.0) - 1.0));
  float _v0 = length(_cse0);
  float _v1 = ((0.3 / max(_v0, 0.001)) + (U.time * 1.4));
  _ret = vec4((((mix(vec3(1.0, 0.62, 0.28), vec3(0.42, 0.3, 0.55), ((sin((_v1 * 0.9)) * 0.5) + 0.5)) * ((smoothstep(-0.6, 0.6, (sin((((atan(_cse0.y, _cse0.x) / 3.14159265) + ((_v1 * U.twist) * 0.08)) * 12.566)) * sin((_v1 * 9.4248)))) * 0.55) + 0.35)) * smoothstep(0.0, 0.55, _v0)) * clamp((1.15 - (_v0 * 0.35)), 0.0, 1.0)), 1.0);
}
